If you’re looking to weld austenitic stainless steels, the AWS Class ER308/308L Submerged Arc Welding (SAW) wire and flux are your go-to options. These materials are specifically crafted for welding popular grades like 304, 304L, 308, and 308L. They offer fantastic weldability, impressive corrosion resistance, and solid mechanical properties, making them perfect for high-temperature jobs. The ER308/308L classification is all about keeping the carbon content low, which helps prevent carbide precipitation and boosts the alloy’s resistance to intergranular corrosion.
When it comes to the chemical makeup of ER308/308L filler materials, you can expect a maximum carbon (C) content of 0.03%, chromium (Cr) ranging from 19.5% to 22.0%, nickel (Ni) between 9.0% and 11.0%, and molybdenum (Mo) up to 0.75%. You’ll also find manganese (Mn) between 1.0% and 2.5%, silicon (Si) from 0.30% to 0.65%, phosphorus (P) and sulfur (S) both capped at 0.03%, and copper (Cu) up to 0.75%. This unique blend of elements ensures that the filler material can create strong, corrosion-resistant welds even in high-temperature settings.
| Classification | AWS A5.9, ER308/308L |
| Form | Welding Fluxes and Wires |
| Type Of Welding | Submerged Arc Welding |
| Thickness available | Upto 4 mm |
| AWS ER308/308L SAW & Flux Application & uses |
|
| C | Mn | Si | Cr | Ni | S | P | Mo | Cu |
| 0.04-0.08 | 1.0-2.5 | 0.30-0.65 | 19.5-22.0 | 9.0-11.0 | 0.03 | 0.03 | 0.50 | 0.75 |
| Tensile Strength | 86,500 psi |
|---|---|
| Yield Strength | 57,500 psi |
| Elongation (%) | 39% |
Contact us to get a quick quote for your requirement.
Alloy ER308/308L SAW and Flux are used in submerged arc welding for stainless steel, providing high-quality, strong welds with excellent corrosion resistance and a clean, slag-free finish.
AWS A5.9 ER308/308L SAW and Flux Welding Wire is designed for submerged arc welding of stainless steel, offering high-strength welds, superior corrosion resistance, and a smooth, slag-free finish.
AWS Class ER308/308L Submerged Arc Welding Flux provides excellent arc stability and weld quality, producing clean, slag-free welds with high corrosion resistance and strength for stainless steel applications.
As for the mechanical properties, ER308/308L filler materials typically boast a tensile strength of around 88,000 psi (about 610 MPa), a yield strength of approximately 59,000 psi (about 410 MPa), and an elongation of 39%. This means they have great ductility and toughness, ensuring that any welds made with them are not only durable but also able to handle the stresses of high-temperature applications.
AWS Class ER308/308L SAW and Flux are widely used for welding austenitic stainless steel in applications such as piping, structural components and tanks. They are useful for industries like chemical processing, food and beverage and pharmaceuticals. Where corrosion resistance and high strength are crucial. These materials are also employed in the construction of pressure vessels and heat exchangers, providing strong, durable welds that can withstand harsh environments and demanding operational conditions.
